Brother MFC-J680DW User Manual

3
In the Orientation field, select either the
Portrait or Landscape option to set the
orientation of your printout.
If your application software contains a
similar layout feature, we recommend
using the one in the application.
4
Click the 2-sided / Booklet drop-down
list, and then select 2-sided.
5
Click the 2-sided Settings button.
6
Select one of the options from the
2‑sided Type menu.
7
Select the Binding Offset check box if
you want to specify the offset for binding
in inches or millimeters.
8
Click OK to return to the printer driver
window.
9
Change other printer settings if needed.
The Borderless feature is not available
when using this option.
10
Click OK again, and then complete your
print operation.
Print More Than One Page
on a Single Sheet of Paper
(N in 1) (Windows
®
)
1
Select the print command in your
application.
2
Select Brother MFC-XXXX (where
XXXX is the name of your model), and
then click the printing properties or
preferences button.
The printer driver window appears.
3
In the Orientation field, select either the
Portrait or Landscape option to set the
orientation of your printout.
If your application software contains a
similar layout feature, we recommend
using the one in the application.
4
Click the Multiple Page drop-down list,
and then select the 2 in 1, 4 in 1, 9 in 1,
or 16 in 1 option.
5
Click the Page Order drop-down list,
and then select your page order.
6
Click the Border Line drop-down list,
and then select your border line type.
7
Change other printer settings if needed.
8
Click OK, and then complete your print
operation.
Print Photos from
ControlCenter4 (Windows
®
)
You can print and edit photos using various
ControlCenter features.
In the following steps, the ControlCenter
Home mode is used as an example.
1
Make sure you have loaded the correct
media in the paper tray.
2
Click the
(ControlCenter4) icon in
the task tray, and then click Open.
16

Brother MFC-J680DW Specifications

General

Wi-Fi	Yes
Ethernet LAN	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	64-bit WEP, 128-bit WEP, SSID, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-PSK, WPS
Online services supported	Box, Dropbox, Evernote, Flickr, Google Drive, OneDrive, OneNote, Picasa
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Sustainability certificates	Nordic Swan Ecolabel, Blue Angel, ENERGY STAR
Display	LCD
Control type	Touch
Product color	Black
Display diagonal	2.7 \
Market positioning	Home & office
Print technology	Inkjet
Maximum resolution	6000 x 1200 DPI
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	12 ipm
Print speed (ISO/IEC 24734) color	10 ipm
Print speed (black, normal quality, A4/US Letter)	- ppm
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 1200 DPI
Maximum number of copies	99 copies
Scan to	E-mail, File, Image, Memory Card, OCR, USB
Scan drivers	ICA, TWAIN, WIA
Scanner type	Flatbed scanner
Grayscale levels	256
Input color depth	30 bit
Maximum scan area	A4 (210 x 297) mm
Output color depth	24 bit
Image formats supported	JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	1200 x 2400 DPI
Digital sender	-
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	4
Faxing	Color faxing
Fax memory	200 pages
Modem speed	14.4 Kbit/s
Fax resolution (black)	203 x 203 DPI
Envelopes sizes	C5, Com-10, DL
Photo paper sizes	10x15, 13x18, 13x20 cm
Custom media width	148 - 215.9 mm
Custom media length	148 - 355.6 mm
Paper tray media types	Coated paper, Envelopes, Glossy paper, Photo paper, Plain paper, Recycled paper
Non-ISO print media sizes	2L, Executive (184 x 267mm), Index card, L, Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Compatible memory cards	MMC, MMC Mobile, MMC+, MMCmicro, MS Duo, MS PRO Duo, MicroSD (TransFlash), MiniSD, MiniSDHC, SD, SDHC, SDXC
Standard interfaces	USB 2.0, Wireless LAN
Noise level	50 dB
Bundled software	Brother ControlCenter 2 Brother ControlCenter 4 Nuance Paperport 14 SE
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Mobile operating systems supported	Android, Windows Phone, iOS
Server operating systems supported	Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2012 x64
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Paper input type	Paper tray
Total input capacity	100 sheets
Total output capacity	50 sheets
Multi-Purpose tray input capacity	20 sheets
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.2 W
Power consumption (ready)	3.5 W
Power consumption (sleep)	1.3 W
Power consumption (average operating)	19 W
Package depth	249 mm
Package width	477 mm
Package height	457 mm
Package weight	10100 g
Storage temperature (T-T)	20 - 33 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	341 mm
Width	400 mm
Height	172 mm
