Page #68 background imageLoading...
Page #68 background image
Troubleshooting for Wireless LAN setup
Wireless LAN Report Error Codes
If the Wireless LAN Report shows that the connection failed, check the error code on the printed
report and see the corresponding instructions in the table:
Error Code Problem and Recommended Solutions
TS-01 The wireless setting is not activated, change the wireless setting to ON.
If a network cable is connected to your machine, disconnect it and change the
wireless setting of your machine to ON.
TS-02 The wireless access point/router cannot be detected.
1. Check the following two points:
Unplug the power to your wireless access point/router, wait for 10
seconds, and then plug it back in.
If your WLAN access point/router is using MAC address filtering,
confirm that the MAC address of the Brother machine is allowed in the
filter.
2. If you manually entered the SSID and security information (SSID/
authentication method/encryption method/Network Key), the information
may be incorrect.
Reconfirm the SSID and security information and re-enter the correct
information if needed.
TS-04 The Authentication/Encryption methods used by the selected wireless access
point/router are not supported by your machine.
For infrastructure mode, change the authentication and encryption methods of
the wireless access point/router. Your machine supports the following
authentication methods:
WPA-Personal
TKIP or AES
WPA2-Personal
AES
Open
WEP or None (without encryption)
Shared key
WEP
If your problem is not solved, the SSID or network settings you entered may
be incorrect. Confirm the wireless network settings.
For Ad-Hoc Mode, change the authentication and encryption methods of your
computer for the wireless setting. Your machine supports Open authentication
only, with optional WEP encryption.
52

Table of Contents

Other manuals for Brother MFC-J680DW

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Brother MFC-J680DW and is the answer not in the manual?

Brother MFC-J680DW Specifications

General IconGeneral
Wi-FiYes
Ethernet LANNo
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms64-bit WEP, 128-bit WEP, SSID, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-PSK, WPS
Online services supportedBox, Dropbox, Evernote, Flickr, Google Drive, OneDrive, OneNote, Picasa
Mobile printing technologiesApple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Sustainability certificatesNordic Swan Ecolabel, Blue Angel, ENERGY STAR
DisplayLCD
Control typeTouch
Product colorBlack
Display diagonal2.7 \
Market positioningHome & office
Print technologyInkjet
Maximum resolution6000 x 1200 DPI
Duplex printing modeAuto
Print speed (ISO/IEC 24734) mono12 ipm
Print speed (ISO/IEC 24734) color10 ipm
Print speed (black, normal quality, A4/US Letter)- ppm
Copier resize25 - 400 %
Maximum copy resolution1200 x 1200 DPI
Maximum number of copies99 copies
Scan toE-mail, File, Image, Memory Card, OCR, USB
Scan driversICA, TWAIN, WIA
Scanner typeFlatbed scanner
Grayscale levels256
Input color depth30 bit
Maximum scan areaA4 (210 x 297) mm
Output color depth24 bit
Image formats supportedJPG, TIF
Maximum scan resolution19200 x 19200 DPI
Optical scanning resolution1200 x 2400 DPI
Digital sender-
Printing colorsBlack, Cyan, Magenta, Yellow
Maximum duty cycle- pages per month
Number of print cartridges4
FaxingColor faxing
Fax memory200 pages
Modem speed14.4 Kbit/s
Fax resolution (black)203 x 203 DPI
Envelopes sizesC5, Com-10, DL
Photo paper sizes10x15, 13x18, 13x20 cm
Custom media width148 - 215.9 mm
Custom media length148 - 355.6 mm
Paper tray media typesCoated paper, Envelopes, Glossy paper, Photo paper, Plain paper, Recycled paper
Non-ISO print media sizes2L, Executive (184 x 267mm), Index card, L, Letter (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
Maximum ISO A-series paper sizeA4
Compatible memory cardsMMC, MMC Mobile, MMC+, MMCmicro, MS Duo, MS PRO Duo, MicroSD (TransFlash), MiniSD, MiniSDHC, SD, SDHC, SDXC
Standard interfacesUSB 2.0, Wireless LAN
Noise level50 dB
Bundled softwareBrother ControlCenter 2 Brother ControlCenter 4 Nuance Paperport 14 SE
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Mobile operating systems supportedAndroid, Windows Phone, iOS
Server operating systems supportedWindows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2012 x64
Windows operating systems supportedWindows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Paper input typePaper tray
Total input capacity100 sheets
Total output capacity50 sheets
Multi-Purpose tray input capacity20 sheets
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (off)0.2 W
Power consumption (ready)3.5 W
Power consumption (sleep)1.3 W
Power consumption (average operating)19 W
Package depth249 mm
Package width477 mm
Package height457 mm
Package weight10100 g
Storage temperature (T-T)20 - 33 °C
Operating temperature (T-T)10 - 35 °C
Operating relative humidity (H-H)20 - 80 %
Weight and Dimensions IconWeight and Dimensions
Depth341 mm
Width400 mm
Height172 mm
