Brother MFC-L2700DN Service Manual

5-9
Confidential
1.3.5 Set worker switches (WSW) and print worker switch setting data
(function code: 10, 11)
[1] Set worker switches (WSW) (function code: 10)
<Function>
The worker switches shown in the table below can be used to set the function to satisfy various
requirements. These switch settings can be changed using the keys on the control panel.
The worker switches are factory set to conform with the laws and regulations of the country
the machine is shipped to. Do not change these settings unless necessary.
* Refer to the separate manual for details of worker switches.
WSW No. Function WSW No. Function
WSW01
Dial pulse setting
WSW40
V.34 modem settings
WSW02
Tone signal setting
WSW41
ON-duration of the scanning light source
WSW03
PABX mode setting
WSW42
Internet mail settings
WSW04
Transfer facility setting
WSW43
Function setting 16
WSW05
1st dial tone and busy tone detection
WSW44
Speeding up scanning-1
WSW06
[Redial/Pause] key and 2nd dial tone
detection
WSW45
Speeding up scanning-2
WSW07
Dial tone setting 1
WSW46
PC power monitoring and parallel port settings
WSW08
Dial tone setting 2
WSW47
Switching between high- and full-speed USB
WSW09
Protocol definition 1
WSW48
USB setup latency
WSW10
Protocol definition 2
WSW49
End-of-copying beep
WSW11
Busy tone setting
WSW50
SDAA setting
WSW12
Signal detection condition setting
WSW51
Function setting 17
WSW13
Modem setting
WSW52
Function setting 18
WSW14
AUTO ANS facility setting
WSW53
Function setting 19
WSW15
Redial facility setting
WSW54
Function setting 20
WSW16
Function setting 1
WSW55
Interval for regular developing bias
value correction
WSW17
Function setting 2
WSW56
Function setting 21
WSW18
Function setting 3
WSW57
Function setting 22
WSW19
Transmission speed setting
WSW58
Function setting 23
WSW20
Overseas communication mode setting
WSW59
Function setting 24
WSW21
TAD setting 1
WSW60
Function setting 25
WSW22
ECM and call waiting caller ID
WSW61
Scanning light intensity to judge to be stable 1
WSW23
Communication setting
WSW62
Scanning light intensity to judge to be stable 2
WSW24
TAD setting 2
WSW63
Function setting 26
WSW25
TAD setting 3
WSW64
Language / default paper size setting
WSW26
Function setting 4
WSW65
Paper support setting
WSW27
Function setting 5
WSW66
Change of the setting is prohibited
WSW28
Function setting 6
WSW67
Change of the setting is prohibited
WSW29
Function setting 7
WSW68
Change of the setting is prohibited
WSW30
Function setting 8
WSW69
Change of the setting is prohibited
WSW31
Function setting 9
WSW70
Change of the setting is prohibited
WSW32
Function setting 10
WSW71
Change of the setting is prohibited
WSW33
Function setting 11
WSW72
Change of the setting is prohibited
WSW34
Function setting 12
WSW73
Change of the setting is prohibited
WSW35
Function setting 13
WSW74
ADF stop control
WSW36
Function setting 14
WSW75
Switch back ejection distance
WSW37
Function setting 15
WSW76
Set the limit for the number of
documents to be ejected in reverse
order for single-side scanning from ADF
WSW38
V.34 transmission settings
WSW77
Set the limit for the number of
documents to be ejected in reverse
order for duplex scanning from ADF
WSW39
V.34 transmission speed
WSW78
Recording stop function when the drum
reaches the end of life

Brother MFC-L2700DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Duplex printing mode	Auto
Print speed (black, normal quality, A4/US Letter)	24 ppm
Product color	Gray
Market positioning	Home & office
Display number of lines	2 lines
Display number of characters	16
Custom media width	76.2 - 215.9 mm
Custom media length	127 - 355.6 mm
Paper tray media weight	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Sound pressure level (printing)	49 dB
Sound pressure level (quiet mode)	45 dB
Maximum copy resolution	600 x 600 DPI
Scanner type	Flatbed & ADF scanner
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Wi-Fi	-
Cabling technology	10/100Base-T(X)
Security algorithms	SMTP-AUTH, SNMP
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print
Package depth	517 mm
Package width	567 mm
Package height	435 mm
Package weight	14400 g
Sustainability certificates	Blue Angel, ENERGY STAR
Mac operating systems supported	Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Linux operating systems supported	SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3, SuSE Linux 11, SuSE Linux 11.1, SuSE Linux 11.2, SuSE Linux 12.0
Server operating systems supported	Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2012 x64
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Total input capacity	250 sheets
Total output capacity	100 sheets
Auto document feeder (ADF) input capacity	35 sheets
Maximum duty cycle	- pages per month
Recommended duty cycle	250 - 2000 pages per month

Weight and Dimensions

Depth	398.5 mm
Width	409 mm
Height	316.5 mm
