Fig. 5-6
Fig. 5-7
Fig. 5-8
For models without keypad
(1) Press the [▲] or [▼] key in the initial
state of maintenance mode to display
"MAINTENANCE 13" on the LCD, and
press the [OK] key. "00:" is displayed on
the LCD.
(2) Press the keys on the control panel
according to the numbers provided in
the figure below. Each time the key is
pressed, the corresponding figure is
displayed on the LCD in decimal
notation. Check that the number and the
key name displayed on the LCD
matches the number assigned to the key
that has been pressed. If the keys are
pressed in the incorrect order, "INVALID
OPERATE" is displayed on the LCD.
Press the [Stop] key and try again with
the correct key.
(3) When the key operation is normal, the
machine returns to the initial state of
maintenance mode when the last key is
pressed. To cancel operation and return
to the initial state of maintenance mode,
press the [Stop] key.
For models with keypad
(1) Press the [1], and then the [3] key in the
initial state of maintenance mode. "00" is
displayed on the LCD.
(2) Press the keys on the control panel
according to the numbers provided in
the figure below. Each time the key is
pressed, the corresponding figure is
displayed on the LCD in decimal
notation. Check that the number and the
key name displayed on the LCD
matches the number assigned to the key
that has been pressed. If the keys are
pressed in the incorrect order, "INVALID
OPERATE" is displayed on the LCD.
Press the [X] or [Stop] key and try again
with the correct key.
(3) When the key operation is normal, the
machine returns to the initial state of
maintenance mode when the last key is
pressed. To cancel operation and return
to the initial state of maintenance mode,
press the [X] or [Stop] key.
To Next Page
