NOTE
Before performing any maintenance, power off the label printer. If you use batteries,
remove the batteries and if you use AC Adapter, unplug the AC Adapter.
XCleaning the label printer case
Wipe the case with a soft, dry cloth to remove dirt or dust. If the case is heavily soiled, wipe
it with a cloth dampened with some water.
NOTE
Do not use solvents or agents such as benzene, paint thinner, or alcohol, which may
damage the label printers surface.
XCleaning the Print Head
Dirt on the Print Head may cause blank lines, faint type, or missing characters.
Use an optional dedicated Head Cleaning Cassette (TZe-CL3) or use a cotton swab to
gently wipe dirt from the Print Head.
NOTE
Insert the Head Cleaning Cassette in the machine, and press the Power Button twice
quickly. Cut the Cleaning Tape after it is fed. If the problem is not solved after repeating this
process three times, contact Brother Customer Services.
Performing Routine Maintenance
WARNING
DO NOT TOUCH the Print Head. It is very hot and you may get burned.

Brother P-TOUCH CUBE Specifications

General

Printing Technology	Thermal Transfer
Connectivity	Bluetooth
Tape Width	3.5mm, 6mm, 9mm, 12mm
Cutter	Manual
Maximum Print Resolution	180 dpi
Print Speed	20mm/sec
Compatible Tapes	TZe
Power Source	6 x AAA batteries (LR03, HR03) or AC adapter (AD-24, not included)
Model	Brother P-TOUCH CUBE
Mobile Device Compatibility	iOS and Android
Maximum Print Height	9mm
Weight	0.38 kg
Maximum Tape Width	12mm (0.47")
Dimensions	115mm (W) x 115mm (D) x 61mm (H)
