Brother P-TOUCH CUBE User Manual

Make sure your Tape Cassettes display the TZe mark ( ).
Use only tape widths of 3.5 mm, 6 mm, 9 mm, or 12 mm.
If there is a stopper on the TZe Tape Cassette, remove it before installation.
3. Inserting the Tape Cassette
1. Hold the label printer as shown in the
illustration. Open the Cassette Cover
by pressing the mark on its side (1) and
pulling in the direction of the arrow (2).
2. Insert the Tape Cassette following the
drawing marked inside the case.
Confirm that the tip of the tape is
pointed at the Tape Exit Slot.
3. Press the Tape Cassette into the label
printer until it snaps into place.
NOTE
 
Guide, pull the tip to remove any slack
in the tape.
 
the unit when inserting or removing
the Tape Cassette.
4. Insert the two hooks at the rear of the
Cassette Cover into the slots on the
label printer (3). Push the Cassette
Cover closed (4), making sure it locks
into place.
Cassette Cover
2
1
Print Head
Tape Guide
End of Tape
3
4

Brother P-TOUCH CUBE Specifications

General

Printing Technology	Thermal Transfer
Connectivity	Bluetooth
Tape Width	3.5mm, 6mm, 9mm, 12mm
Cutter	Manual
Maximum Print Resolution	180 dpi
Print Speed	20mm/sec
Compatible Tapes	TZe
Power Source	6 x AAA batteries (LR03, HR03) or AC adapter (AD-24, not included)
Model	Brother P-TOUCH CUBE
Mobile Device Compatibility	iOS and Android
Maximum Print Height	9mm
Weight	0.38 kg
Maximum Tape Width	12mm (0.47")
Dimensions	115mm (W) x 115mm (D) x 61mm (H)
