Insert the Tape Cassette following the drawing
marked inside the case. Gently press the
Cassette into the P-touch labeling system
until it locks into place.
• Make sure your Tape Cassette is marked or .
• Use only Brother TZe or HGe tapes with this machine.
Close the Cassette Cover and gently press
until it locks into place.
NOTE
If you prefer to use the optional AC Adapter
(AD-24ESA) instead of using batteries:
1. Insert the Power Adapter cord into the AC Adapter
Socket on the side of the P-touch labeling system.
2. Insert the Power Adapter into an earthed AC
electrical socket.
Tape Exit Slot
Toothed Wheel
Cutter Edge
End of Tape
Tape Guides
