Brother RH-9820 Service Manual

6. ASSEMBLY
RH-9820
73
6-8. Looper base mechanism
* Refer to the detailed descriptions on pages 75 to 78 for details on A to F in the illustration.
* Apply the grease specified by Brother (MOLYKOTE LONGTERM W2 manufactured by Dow Corning
Corporation) in the places indicated by .
1093B
Refer to “7-24-2. Adjusting
the upper movable knife”.
C
D
E
F
R
e
f
er
t
o
“7-24-2.
A
djusting
the upper
movable
knife”.
J
K
Refer to “7-28.
A
djusting the position
of the lower thread
presser <-02
specifications only>”.
Refer to “7-24-3.
A
djusting the
position of the thread
trimmer lever
bracket”.
Refer to “7-11
A
djusting the
height of the
throat plate”.
Refer to “7-8.
A
djusting the
needle guard”.
Refer to “7-1. Adjusting the heights of the
spreaders and loopers” and “7-7. Adjusting
the clearance between the loopers and
needle”.
Longe
r
end
A
H
I
B
G
