SPECIFICATIONS
SYSTEM MODELS
ENGINE 800R E-TEC
Engine type Rotax
®
797, liquid cooled w/Reed valve, 3D-RAVE
Cylinders
2
Displacement 799.5 cm³ (48.79 in³)
Bore 82 mm (3.23 in)
Stroke 75.7 mm (2.98 in)
Maximum horsepower engine RPM 8100 / 7900 (ECS2)
Fuel injection system E-TEC direct injection
Exhaust system Single tuned pipe, baffle muffler
Engine oil
XPS SYNTHETIC 2-STROKE OIL(F)
(P/N 619 590 106)
Engine oil tank capacity 2.9 L (3.06 qt (U.S. liq.))
Coolant
Ethyl glycol/water mix (50% coolant, 50%
distilled water). Use
LONG LIFE ANTIFREEZE(F)
(P/N 619 590 204)
or coolant specifically
designed for aluminum engines
Cooling system capacity 6.2 L (6.55 qt (U.S. liq.))
Recommended fuel type Premium unleaded
Minimum octane rating
95 (Fuel which may contain up to 10% ethanol)
Fuel tank capacity 41 L (10.8 U.S. gal.)
DRIVE SYSTEM
Type TRA VII™
Drive pulley
Engagement 3800 RPM ± 100
Driven pulley type QRS-SS
Drive sprocket number of teeth
7
Gearbox oil
XPS SYNTHETIC GEAR OIL (75W 140 hypoid)
(P/N 619 590 182)
Gearbox oil capacity 600 ml (20.3 U.S. oz)
1st
3.23
2nd
1.98
Gear ratio
R
4.06
Track nominal width
500mm
Track nominal length
392.3mm
Track profile height
44 mm
Deflection 40 mm to 50 mm (1.575 in to 1.969 in)
Track tension
Force
(1)
7.3 kgf (16 lbf)
110
