CONTROLS, INSTRUMENTS AND EQUIPMENT
grammed by your authorized Lynx
dealer to accept the other vehicles
D.E.S.S. keys.
6) Emergency Engine
Stop Switch
The emergency engine stop switch is
located on the RH side of handlebar.
Push-pull type switch.
To stop the engine in an emergency,
select OFF position (down) and simul-
taneously apply the brake. To restart,
button must be at the ON position (up).
mmo2016-008-202_a
OFF POSITION
To allow engine starting, the switch
must be in the ON position (UP).
mmo2016-008-201_a
ON POSITION
All operators of the snowmobile
should familiarize themselves w ith the
function of the emergency engin
estop
switch by using it several times on first
outing and whenever stopping the en-
gine thereafter. This engine stopping
procedure w ill become a reflex and will
prepare operators for emergency situ-
ations requiring its use.
WARNING
If the switch has been used in an
emergency caused by a suspected
malfunction, the source of the mal-
function should be determined
and corrected before restarting
engine. See an authorized Lynx
dealer for servicing.
7) 12-Volt Power Outlet
On all models, a 12-volt power outlet is
installed at front, near steering column.
A 12-volt electric appliance may be
connected to that jack connector.
If you need continuous current contact
an authorized Lynx dealer.
8) Multifunction Switch
Multifunction switch is located on the
LH side of handlebar.
fmo2014-003-003_a
1. Start button
2. Headlights dimmer switch
3. Heated grips
4. Heated throttle lever
5. Mode/set button
38
