CONTROLS, INSTRUMENTS AND EQUIPMENT
Start Button
Press to start engine. Refer to
ENGINE
STARTING PROCEDURE
in the
OPER-
ATING INSTRUCTIONS
subsection.
Headlights Dimmer Switch
Press to select HI or LOW beam.
Lights are automatically ON when the
engine is running.
Heated Grips and Throttle Lever
Switch
NOTE: Under 1900 RPM, heated grips
or throttle lever will be limited at 50%.
Depress switch as required to select
heating intensity to keep your hands at
a com fortable temperature.
Heated Grips Sw itch
fmo2014-003-003_b
TYPICAL
1. Heated grips switch
2. Increase heat
3. Decrease heat
The heating intensity is displayed via
the multifunction display.
mmo2007-009-043_b
HEATING INTENSITY DISPLAY
1. Colder (Less heat)
2. Warmer (More heat)
Heated grips will be in OFF p os ition
when there are no bars displayed on
the gauge.
Heated Throttle Lever Switch
fmo2014-003-003_c
TYPICAL
1. Heated throttle lever switch
2. Increa se heat (Warmer)
3. Decrease heat (Colder)
NOTE: The heating intensity is dis-
played via the multifunction display
with the activation of the throttle lever
switch. When released, display will
return to fuel tank level.
_______________
39
