Operating & Service Manual Version 002 BRUKER BIOSPIN 11 (53)
Initial Turn on Procedure
Initial Turn on Procedure 3.5
The following list describes how to turn on the BLAH1000 E Amplifier 700-
900MHz and what should be seen as this occurs.
Before starting this procedure, make sure that you have properly followed the
instructions in section "System Check" on page 10.
1. Connect together the amplifier and the external power supply, connect it to the
AC line and turn the line switch to ON.
2. Observe the indicators on the front panel of the amplifier:
- The +32V ON LED's will illuminate,
- The +15V, -15V and +3,3V ON LED's will illuminate.
3. System is now fully operational.
