Bruker BLAH1000 E User Manual

Operating & Service Manual Version 002 BRUKER BIOSPIN 15 (53)
Front Panel Description
Device Front View 4.1.4
Figure 4.1. BLAH1000 E Amplifier 700-900MHz Front Panel Design
Figure 4.2. BLAH1000 E Amplifier 700-900MHz Front Panel View
BLAH1000 E 700-900MHz
RF PULSE
+32V
+15V
-15V
+3.3V
RF POW. FLT
OVERHEAT
OVERDRIVE
D. C.
P. W.
MISMATCH
1000W ON
MAIN OUT
IN 1
AUX OUT
ETH. 10/100
H1000/H100
1000W/100W
IN 2
IN 3
SEL
MAIN OUT
1000W/100W
BLNK
Tx Rx
18
