Operating & Service Manual Version 002 BRUKER BIOSPIN 43 (53)
7
Specifications 7
Common Characteristics 7.1
Table 7.1. Amplifier Common Characteristics
Constant Internal Protection Supplies, fans faults and over temperature.
Forward Power : peak & CW power, pulse width and duty cycle.
Reflected Power : peak & CW power, self resetting protection
shuts the amplifier off if the load VSWR is excessive.
Front Panel Indicators Amplifier Status Led Board.
Front Panel Interfaces 1 x I/O 8 pins RJ45 connector.
Front Panel Controls 1 x SEL H1000/H100 control signal.
Front Panel Connectors 3 x RF input,
2 x RF output,
1 x blanking input (gating).
Rear Panel Connectors 15 pins DIN 41612-H ERNI female connector.
(power supply connection).
Cooling System Forced-air cooling (from front to rear).
Size 19" rack cabinet x 3U height x 520mm depth.
Weight 23kg
Power Requirements Additional 208-230 VAC ± 10% single phase 50-60Hz switched
power supply, Bruker Biospin part number W1304007.
A front panel circuit breaker turns the AC Line ON/OFF.
A status led board, on the front panel, indicates the power supplies
condition.
Size : 19" rack cabinet x 2U height x 480mm depth.
Weight : 14kg.
