Bruker NMR 400 89 Ascend DNP User Manual

73
ZTKS0243 / Z31993 / 03
Technical Data MS 400‘89 Ascend DNP
Dimensions Cryostat Value Unit
C
Operational Ceiling Height
3480 mm
D-RT
Diameter RT Bore Tube
89 mm
D1
Diameter RT vessel
745 mm
D2
Diameter Bottom Plate
795 mm
H1
Height Cryostat (bottom plate to top flange)
1205 mm
H2
Height Cryostat (minimum height for transportation)
1604 mm
H3
Height Cryostat (bottom plate to flow system)
1763 mm
S
Height Magnet Stand (floor to bottom plate)
950 mm
M1
Distance magnetic Center to bottom flange
refer to Table A.17,
page 96
M2
Distance magnetic center to top flange
refer to Table A.17,
page 96
Table A.2: Dimension Cryostat - Front View
