Putting cables through the sheet metal pedestal
Working step Note
1. Make holes
in sheet metal
pedestal
Pre-cut outbreaks are pro-
vided in the area, where
the sheet metal pedestal is
joined. Punch out the pre-
cut outbreaks and deburr
the holes.
2. Put the rubber
grommets inside
The rubber grommets are
attached in accessory kit
3. Pull the cables
out
Leave a spare length un-
derneath the pedestal. It
is helpful during exchange
of components, when the
plug-in connector is acces-
sible without removing the
sheet metal pedestal.
Illustration 63: Cables
led through the sheet
metal pedestal
