3
?
4
9
12
11
6
2
13
7
3
5
8
10
ITEM NO. Rail Assembly/QTY. PART NO. DESCRIPTION
1 1 DSP-00150 SRE DISPLAY ASSEMBLY
** 2 8 FNF-28101 .281" HOLE X .92" LG FINNED FASTENER (NATURAL)
3 1 LUB-00102 LUBRI-PLATE 1.75 OZ. TUBE
4 1 METW-06001 M6 EXTERNAL TOOTH WASHER
** 5 4 MHCS-08007 M8 X 1.25 X 16mm LG HEX HEAD CAP SCREW
** 6 4 MKEP-08125 M8 X 1.25 KEPS NUT
7 1 MSHS-06008 M6 X 1 X 25MM LG METRIC SOCKET HEAD CAP SCREW
8 3 MSSSA-05002 M5 X .08 X 16MM SET SCREW (CONE POINT WITH ANTI-SEIZE)
9 1 SRE-20311 DISPLAY GEAR RACK (40")
10 2 SRE-27206 END CAP
** 11 4 SRE-27255 CONTACT STRIP BLOCK
12 1 SRE-27286 FINAL LIMIT RAMP ASSEMBLY
13 1 SRE-27292 48" DISPLAY RAIL
14 3 SRE-27417 CLAMP ASSEMBLY
15 1 SRE-K-2732 4' RAIL ELECTRICAL PARTS KIT
NOTE:
** ITEMS ARE PART OF SRE-K-2726
for your independence
SHEET 1 OF 1
SRE-2750 ROLLING DISPLAY w/44" RAIL
DSP-A-2751
REV. 3 (4303)(12-1-09)(JJP)
©2009 Bruno Independent Living Aids, Inc.
