PHYSICAL DATA — 579F180-300
UNIT SIZE 579F 180 216 240 300
NOMINAL CAPACITY (tons) 15 18 20 25
OPERATING WEIGHT (lb)
Unit
Al/Al* 1650 2150 2200 2250
Economizer 110 110 110 110
Roof Curb† 200 200 200 200
COMPRESSOR Semi-Hermetic
Model No. ...Quantity
(Number of Cylinders)
06D-537...1 (6)
06D-824...1 (6)
06D-818...1 (4)
06D-824...2 (6) 06D-328...2 (6)
Oil (oz) 115 88,115 115 ea 128 ea
No. of Cylinders (per circuit) 666 6
Cooling Capacity Stages (%) 0, 66, 100 0, 57, 100 0, 50, 100 0, 50, 100
REFRIGERANT TYPE R-22
Expansion Device TXV Acutrol™ Refrigerant Metering Device
Operating Charge (lb-oz)
Circuit 1** 19-4 13-4 12-13 16-12
Circuit 2 — 11-0 12-13 15-12
CONDENSER COIL
3
⁄
8
-in. Enhanced Copper Tubes, Aluminum Lanced or Copper Fins
Rows...Fins/in. 2...17 3...15 3...15 4...15
Total Face Area (sq ft) 22.2 22.2 22.2 22.2
CONDENSER FAN Propeller Type
Nominal Cfm 10,500 10,500 14,200 14,200
Quantity...Diameter (in.) 3...22 3...22 2...30 2...30
Motor Hp...Rpm
1
⁄
2
...1050
1
⁄
2
...1050 1...1075 1...1075
Watts Input (Total) 1100 1100 3400 3400
EVAPORATOR COIL
3
⁄
8
-in. Enhanced Copper Tubes, Aluminum or Copper Plate Fins, Face Split
Rows...Fins/in. 2...17 3...17 4...15 4...15
Total Face Area (sq ft) 17.9 17.9 17.9 17.9
EVAPORATOR FAN Centrifugal Type
Quantity...Size (in.) 2...10 x 10 2...12 x 12 2...12 x 12 2...12 x 12
Type Drive Belt Belt Belt Belt
Nominal Cfm 6000 7200 8000 10,000
Motor Hp 3.7 5 7
1
⁄
2
10
Motor Nominal rpm 1725 1745 1745 1740
Maximum Continuous Bhp 4.25 5.90
8.7 [208/230 v]
9.5 [460 v]
10.2 [208/230 v]
11.8 [460 v]
Motor Frame Size 56H 184T 213T 215T
Nominal Rpm High/Low ——— —
Fan Rpm Range Low-Medium Static 891-1179 817-1038 1002-1225 1066-1283
High Static 1227-1550 994-1197 1193-1458 1332-1550
Motor Bearing Type Ball Ball Ball Ball
Maximum Allowable Rpm 1550 1550 1550 1550
Motor Pulley Pitch Diameter Low-Medium Static 3.1-4.1 3.7-4.7 5.4-6.6 4.9-5.9
Min/Max (in.) High Static 3.7-4.7 4.9-5.9 5.4-6.6 4.9-5.9
Nominal Motor Shaft Diameter (in.)
7
⁄
8
1
1
⁄
8
1
3
⁄
8
1
3
⁄
8
Fan Pulley Pitch Diameter (in.) Low-Medium Static 6.0 7.9 9.4 8.0
High Static 5.2 8.6 7.9 6.4
Nominal Fan Shaft Diameter (in.) 1
3
⁄
16
1
7
⁄
16
1
7
⁄
16
1
7
⁄
16
Belt, Quantity...Type...Length (in.) Low-Medium Static 1...BX...42 1...BX...46 1...BX...53 2...BX...50
High Static 1...BX...42 1...BX...50 1...BX...50 2...BX...47
Pulley Center Line Distance (in.) 13.5-15.5 13.3-14.8 14.6-15.4 14.6-15.4
Speed Change per Full Turn of Low-Medium Static 48 37 37 36
Movable Pulley Flange (rpm) High Static 55 34 44 45
Movable Pulley Maximum Full Turns
From Closed Position
555 5
Factory Setting 3.5 3.5 3.5 3.5
Factory Speed Setting (rpm) Low-Medium Static 1035 934 1120 1182
High Static 1389 1104 1328 1470
Fan Shaft Diameter at Pulley (in.) 1
3
⁄
16
1
7
⁄
16
1
7
⁄
16
1
7
⁄
16
LEGEND
Al — Aluminum
Bhp — Brake Horsepower
Cu — Copper
TXV — Thermostatic Expansion Valve
*Evaporator coil fin material/condenser coil fin material.
†Weight of 14-in. roof curb.
**On 579F180-300 units, Circuit 1 consists of lower portion of condenser coil and
lower portion of evaporator coil, and Circuit 2 is the upper portion of both coils.
††Rollout switch lockout is manually reset by interrupting power to unit or resetting
thermostat.
\The 579F300 unit requires 2-in. industrial-grade filters capable of handling face
velocities of up to 625 ft/min (such as American Air Filter no. 5700 or
equivalent).
NOTE: The 579F180-300 units have a low-pressure switch (standard) located on
the suction side.
12
