ACCESSORY DIMENSIONS
Roof Curb — 580D036-072
ROOF CURB
ACCESSORY
‘‘A’’
UNIT SIZE
580D
CRRFCURB001A00 18-29 [356]
036-072
CRRFCURB002A00 28-09 [610]
NOTES:
1. Roof curb accessory is shipped unassembled.
2. Insulated panels.
3. Dimensions in [ ] are in millimeters.
4. Roof curb: galvanized steel.
5. Attach ductwork to curb (flanges of duct rest on
curb).
6. Service clearance 4 ft on each side.
7. Direction of airflow.
UNIT SIZE
580D
‘‘B’’ ‘‘C’’
‘‘D’’ ALT
DRAIN
HOLE
‘‘E’’
GAS
POWER CONTROL
CONNECTOR
PKG ACY
036-072
18-9
11
⁄ 16 9
[551]
18-49
[406]
1
3
⁄ 4 9 [45]
3
⁄ 4 9 NPT
3
⁄ 4 9 NPT
1
⁄ 2 9 NPT
CRBTMPWR001A00*
(Thru-The-Bottom)
3
⁄ 4 9 NPT 1
1
⁄ 4 9 NPT
1
⁄ 2 9 NPT
CRBTMPWR002A00*
(Thru-The-Bottom)
*Either connector package available for either roof curb.
