ACCESSORY DIMENSIONS (cont)
Horizontal Supply/Return Adapter Installation
579F180-300
NOTE: 389210-201 is a fully factory preassembled horizontal
adapter and includes an insulated high static regain transition
duct which substantially improves fan static performance.
The Barometric Relief Damper and Power Exhaust accesso-
ries are not available with the horizontal adapter.
ACCESSORY
PACKAGE NO.
CURB
HEIGHT
DESCRIPTION
389270-201
18-119
(584)
Pre-Assembled, High Static,
Horizontal Adapter
Power Exhaust
(579F180-300)
2'-1 5/8"
2'-2 1/16"
1'-6 5/16"
24
