Bryant 589A - Superheat Charging Table, 588 A048 (Carrier Scroll Compressor); Superheat Charging Table, 588 A048 (Copeland Scroll Compressor); Superheat Charging Table, 588 A060

Table 8F — Superheat Charging Table, 588A048 (Carrier Scroll Compressor)
TEMP (F)
OUTDOOR
ENTERING
AIR
INDOOR AIR — CFM
1600
Indoor Air — Ewb (F)
54 56 58 60 62 64 66 68 70 72 74 76
65 SPH 15.5 15.5 15.6 15.6 17.6 19.6 21.6 22.8 24.0 25.2 25.2 25.3
70 SPH 11.7 11.8 11.8 11.8 13.9 16.0 18.0 20.1 22.2 24.3 24.3 24.3
75 SPH 8.0 8.0 8.0 8.0 10.2 12.3 14.5 17.4 20.4 23.3 23.3 23.3
80 SPH 6.0 6.0 6.0 6.0 8.7 11.3 13.9 16.3 18.6 20.9 21.5 22.0
85 SPH ****7.210.3 13.4 15.1 16.8 18.5 19.7 20.8
90 SPH ****5.67.79.912.4 15.0 17.6 18.7 19.8
95 SPH *****5.26.39.813.2 16.7 17.7 18.8
100 SPH ******5.89.112.5 15.8 17.1 18.4
105 SPH ******5.28.411.714.9 16.5 18.1
110 SPH ******6.28.811.414.0 15.9 17.8
115 SPH ******7.19.111.113.1 15.3 17.5
LEGEND
Ewb — Entering Wet Bulb
SPH — Superheat at Compressor (F)
*Do not attempt to charge system under these conditions — refrigerant
slugging may occur.
Table 8G — Superheat Charging Table, 588A048 (Copeland Scroll Compressor)
TEMP (F)
OUTDOOR
ENTERING
AIR
INDOOR AIR — CFM
1600
Indoor Air — Ewb (F)
54 56 58 60 62 64 66 68 70 72 74 76
65 SPH 19.0 19.0 19.0 19.0 21.7 24.3 26.0 27.7 27.9 28.2 28.4 28.6
70 SPH 15.4 15.4 15.4 15.4 18.1 20.8 22.5 24.1 25.1 26.1 27.1 28.1
75 SPH 11.9 11.9 11.9 11.9 14.6 17.2 18.9 20.6 22.3 24.0 25.8 27.5
80 SPH 8.4 8.4 8.4 8.4 11.0 13.7 15.4 17.0 19.5 22.0 24.5 27.0
85 SPH 5.0 5.0 5.0 5.0 7.5 10.1 11.8 13.5 16.7 20.0 23.2 26.4
90 SPH *****6.69.011.414.7 17.9 21.1 24.4
95 SPH ******6.29.412.6 15.9 19.1 22.3
100 SPH *******7.310.6 13.8 17.0 20.3
105 SPH *******5.38.511.815.0 18.2
110 SPH ********6.911.215.5 19.8
115 SPH ********5.310.6 16.0 21.3
LEGEND
Ewb — Entering Wet Bulb
SPH — Superheat at Compressor (F)
*Do not attempt to charge system under these conditions — refrigerant
slugging may occur.
Table 8H — Superheat Charging Table, 588A060
TEMP (F)
OUTDOOR
ENTERING
AIR
INDOOR AIR — CFM
1995
Indoor Air — Ewb (F)
54 56 58 60 62 64 66 68 70 72 74 76
65 SPH 20.1 20.1 20.1 20.1 20.1 20.1 22.6 25.2 25.6 26.1 26.6 27.0
70 SPH 16.5 16.5 16.5 16.5 17.3 18.0 20.6 23.1 24.0 24.8 25.6 26.5
75 SPH 13.0 13.0 13.0 13.0 14.5 16.0 18.5 21.1 22.3 23.5 24.7 25.9
80 SPH 10.9 10.9 10.9 10.9 12.4 13.9 16.5 19.0 20.6 22.2 23.8 25.4
85 SPH 8.9 8.9 8.9 8.9 10.4 11.9 14.4 17.0 18.9 20.9 22.9 24.9
90 SPH 6.9 6.9 6.9 6.9 8.4 9.9 12.4 14.9 17.3 19.6 22.0 24.3
95 SPH 5.0 5.0 5.0 5.0 6.3 7.8 10.3 12.9 15.6 18.3 21.1 23.8
100 SPH *****5.88.310.8 13.9 17.0 20.1 23.2
105 SPH ******6.28.812.3 15.7 19.2 22.7
110 SPH *******6.710.6 14.4 18.3 22.2
115 SPH ********8.913.1 17.4 21.6
LEGEND
Ewb — Entering Wet Bulb
SPH — Superheat at Compressor (F)
*Do not attempt to charge system under these conditions — refrigerant
slugging may occur.
—38—
