1x USB 2.0 type B
OUTPUTS
Analog Outputs: 10 balanced XLR male:
Left, Centre, Right, Left Surround, Right Surround, Left Back, Right Back, Left Auxiliary, Right Auxil-
iary and Subwoofer
16 sindle ended (unbalanced) RCA:
Left, Centre, Right, Left Surround, Right Surround, Left Back, Right Back, Left Auxiliary, Right Auxil-
iary & Subwoofer, 4 tape outputs, 2 Zone Two outputs.
Digital Outputs: 2x HDMI
1x TOSLINK optical
Trigger Inputs/Outputs:
One 12V input and 3 programmable trigger outputs
DATA & CONTROL PORTS:
1x Infra-Red sensor; remote control receiver
1x mini (3mm) phone jack (2 conductor) for auxilliary infra-red control data input
1x Ethernet (RJ45 connector): bilateral data, software download, etc.
INFRA-RED REMOTE CONTROL
Number of buttons: 30
Power Source: two AAA batteries
IR Wavelength: 940nm
PHYSICAL SPECIFICATIONS
Dimensions: 17”W x 14.25”D (not including knobs & connectors) x 5.75”H (not including rubber feet)
17”W x 15.38”D (including knobs & connectors) x 6.25”H (including rubber feet)
Also available with 19”W dress panels (all other dimensions are the same)
Weight: approx 22 lbs (10 kg)
Chassis Temp: 50 deg Celsius max.
Specifications subject to change without notice.
TRADEMARK ACKNOWLEDGEMENTS
