Protocol 3100
46/67 ekr 500 digital Unit Touch – CANopen User Gateway
4.2.2.13 Object 3150h: Web Width Measurement
Index 3150h
Name Web width measurement
Function Reading the measured web width,
defining the basic settings for the web width
measurement
Object Code Record
Value Description
Sub-Index 00h
Description Number of sub-indexes
Object Class Mandatory
Access Ro
Value 5
Sub-Index 01h
Description Current web width
Object Class Mandatory
Access Ro
Data Type Signed32
PDO Mapping No
Unit µm
Value Range Depending on the application
Sub-Index 02h
Description Web width offset
Object Class Mandatory
Access Ro
Data Type Signed32
PDO Mapping No
Unit µm
Value Range Depending on the application
Sub-Index 03h
Description Target width
Object Class Mandatory
Access Rw
Data Type Signed32
PDO Mapping No
Unit µm
Value Range Depending on the application
