3- 2 Service Guide LWE180, LWE200, LPE200, LPE240 © BT Europe AB
Technical data – M4 LPE 240
T-code Valid from serial number Date Order number
660, 661, 662, 497 723984- 2005-05-11 225553-040
Wheels
Drive wheel, mm
Drive wheel for servo, mm
250x75
250x105
Axle pressure without load, kg 460
Axle pressure at rated load, kg 770
Wheel pressure at rated load, kg/cm
2
30
Tightening torque wheel bolts, Nm 130
Fork wheel, Bogie, mm 80x74
Axle pressure without load, kg 175-320
Axle pressure at rated load, kg 1800-2300
Wheel pressure at rated load, kg/cm
2
47-55
Swivel wheel, mm 150x50
Axle pressure without load 175-605
Axle pressure at rated load, kg 120-790
Wheel pressure at rated load, kg/cm
2
12-37
Hydraulic system
Output, kW 2.0
Duty cycle 10%
Minimum carbon brush length, mm 8
Minimum commutator diameter, mm 45
Minimum commutator diameter, mm 43
Pressure at rated load, bar 130
Overflow pressure, bar 145
Pump flow, cc/r 2.5
Tank volume, litre 1.2
Oil type:
at normal temperature
at temperature < -15
o
C
ISO-L-HM32
ISO-L-HV32
Model LPE240
