14
Installing the Antenna
1. Align the Male SMA connector on the transceiver
with the Female SMA connector on the antenna.
2. Turn the antenna clockwise until it is securely
attached.
Removing the Antenna
1. Turn the antenna counterclockwise until it is
detached from the transceiver.
Note: Two antennas are included for optional use.
Installing / Removing the Belt Clip
1. Remove the two parallel screws located
above the battery on the back of the radio.
2. Thread the screws through the holes on the
belt clip.
3. Screw the belt clip back onto the radio body.
Installing Additional Speaker/Microphone (Optional)
1. Pry open the rubber MIC-Headset jack cover.
2. Insert the Speaker/Microphone plug into the double jack.
