Overview
10
Figure 6. Example Screen – During Ultrasound Therapy
Channel Identifier:
Indicates channel A or channel B.
Note: Messages and information associated with
Channel A are provided in the message area on the left
side of the display; messages and information
associated with Channel B are provided in the message
area on the right side of the display.
Ultrasound Runtime:
Displays the current runtime for the channel. Runtime is
the length of time a device has delivered ultrasound
therapy on a channel. Time is displayed in
Running:
A green running indication is displayed when the
ultrasound therapy is ON. Additionally, white bands
animate in channel message area.
Message Area
Message Area
AC Power / Battery Status
