General Information
1
General Information
Introduction
The EkoSonic™ Endovascular System consists of the EkoSonic™ Device and EKOS™
Control System 4.0. The EKOS™ Control System 4.0 consists of the EKOS™ Control
Unit 4.0 (Control Unit), Connector Interface Cable and power cord (see Figure 1).
EKOS™ Control Unit 4.0
Connector
Interface
Cable
Infusion
Catheter
Connector
EkoSonic™ Device
(Infusion Catheter + Ultrasonic Core)
Ultrasonic Core
Connector
Figure 1. EkoSonic™ Endovascular System (Power Cord Not Shown)
(Housing End of
Connector
Interface Cable)
