BTG EKOS - Battery Status and Alerts

Power
19
Figure 7. Screen with AC Power/Battery Status
Battery Gauge
When the Control Unit is turned ON and is powered by the battery, a battery gauge
shows the level of battery charge. As battery charge decreases, the battery gauge
shows the decrease in battery charge. The battery gauge with a red bar indicates a
very low or fully depleted battery.
Item
Description
76% - 100%
51% - 75%
26% - 50%
16%-25%
0% - 15%
If the battery is defective the battery icon is red with
an X.
