Symbols and Indicators
57
Displays Control Unit model number and software version, Connector
Interface Cable and device information and the EKOS help line phone
number.
Displays a line graph that shows the percentage of the maximum
average power delivered for each channel.
Settings Tab:
Displays a configuration menu for setting audible alert volume, screen
brightness and language.
Connected to AC power and battery is charging.
Connected to AC power and battery is fully charged.
Battery charge remaining (76% - 100%).
Battery charge remaining (51% - 75%).
Battery charge remaining (26% - 50%).
Battery charge remaining (16%-25%).
Battery charge remaining (0% - 15%).
