Installation and Connections
SM-DIN/MULTILOOP.. - 2.19 -
GAIN BALANCE
Enter the WRK PARAMETERS menu.
Select GAIN BALANCE.
/
To change the parameter value
This parameter allows you to set a different system reactivity depending on the
tension value.
BAL > 0: the system is more reactive when it has to follow a tension which is
rising. The corrections of a tension which is rising are faster than the
corrections of a tension which is lowering.
BAL < 0: the system is more reactive when it has to follow a tension which is
lowering. The corrections of a tension which is lowering are faster than
the corrections of a tension which is rising.
3 sec to confirm and go back to WRK PARAMETERS menu
SPEED GAIN
(Only if LOOP MODE = MULTILOOP)
Enter the WRK PARAMETERS menu.
Select SPEED GAIN.
/
To change the parameter value [1s … 50s]
3 sec to confirm and go back to WRK PARAMETERS menu
WRK PARAMETERS
→
GAIN BALANCE
WRK PARAMETERS
→
SPEED GAIN
