Installation and Connections
SM-DIN/MULTILOOP.. - 2.20 -
TENSION DROP
(Only for ACTD optional devices)
Enter the WRK PARAMETERS menu.
Select TENSION DROP.
/
To change the parameter value [1% … 99%]
3 sec to confirm and go back to WRK PARAMETERS menu
DF MIN TENS
Enter the WRK PARAMETERS menu.
Select DF MIN TENS
/
To change the parameter value [2…1000 cN] , available for each
single position
3 sec to confirm and go back to WRK PARAMETERS menu
WRK PARAMETERS
→
TENS DROP
WRK PARAMETERS
→
DF MIN TENS
