Bucher C-LRV Series User Manual

C−LRV lift control valve Product description
11/92
300−I−9010212−E−10/08.08
1.3 C−LRV lift control valve
Legend 1
2
4
5
6
7
8
9
10
11
Maximum−pressure setscrew
Bypass−pressure setscrew
Pressure−relief valve
Pilot filter
Test point, G½
Pressure gauge
Pressure gauge shut−off screw
Air−bleed screw
Feedback sensor
Main filter
12
13
14
15
16
17
18
20
22
Flow−rate measuring system
Emergency−lowering valve
DOWN spool
Check valve
UP spool
UP damping jet
DOWN damping jet
Ball valve
Hand pump
Z1
Z2
Z3
Pressure switch port
Pressure switch port
Hand pump port
P
T
Z
D
Pump port
Tank port
Cylinder port
Control cabinet (customer’s)
