C−LRV lift control valve Product description
16/92
300−I−9010212−E−10/08.08
1.3.4 Technical data
300−7−10015573
H*
R*
L*
a
A
Legend 1
2
3
4
Flow−rate measuring system
Pressure−relief valve
DOWN solenoid
UP solenoid
5
6
7
a View A
Z1
Z2
Z3
P
T
Z
Pressure switch port
Pressure switch port
Hand pump port
Pump port
Tank port
Cylinder port
H*
L*
R*
Orientation of Z port
(specify when ordering!)
rear (standard)
left
right
