Controls and MEC2 remote control
5
Logamatic 4321/4322 - Technical specifications are subject to change without prior notice.
15
MEC2 remote control
Fig. 7 MEC2 remote control
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
6 720 618 328-01.1RS
1 Display
2 Dial
3 Continuous heating mode
4 Automatic heating mode by timer
5 Continuously reduced heating mode
6 Input day
7 Input vacation days
8 Select standard display
9 Display for set nominal room temperature
10 Input DHW temperature/reloading
11 Set the time
12 Change temperature values
13 Warm weather shut down (WWSD) temperature
14 Back to standard display
15 Select a timer program
16 Select heating zones/DHW zone
