Basic functions
6
Logamatic 4321/4322 - Technical specifications are subject to change without prior notice.
18
Depending on the way your heating contractor has configured your system, one
or more MEC2 screens may not appear, although the above modules are
installed in your control panel.
Detailed descriptions of MEC2 screens for other modules are included in the
corresponding module documentation.
6.2 Permanent display
There are two different permanent displays. Either one of the factory-set
permanent displays is shown, depending on whether the MEC2 is installed in the
control panel or is installed as a wall-mounted remote control unit.
Factory-set permanent display if the MEC2 is installed in the control panel.
Factory-set permanent display if the MEC2 is installed as a wall-mounted
remote control unit.
USER NOTE
If your heating system is equipped with several heating zones, first select the
correct heating zone (Æ Chapter 7.6). Only then can you select the operating
mode and room temperature.
USER NOTE
The following MEC2 screens only cover the available screens:
– of module ZM434 (standard equipment) and
– of the most common modules FM441 and FM442 (accessories).
boiler temp
outdoor temp
70°F
113°F
room temp
outdoor temp
32°F
67°F
USER NOTE
The display "system supply" will only be shown for multi-boiler systems.
