Parameters Fields
There are multiple parameter fields available. Use the Parameter Scroll button to scroll
through the LCD screen to display the different parameters.
HEAT
TIME
1:00min
COOL
TIME
3:00min
PRESSURE
4200psi
Figure 12 Parameter Fields 1
HEAT TIME Displays the amount of time the specimen will be heated. Use the Increase
or Decrease buttons to select a time between 0 to 20 minutes, in 10-second
increments.
COOL TIME Displays the amount of time a specimen will be cooled. Use the Increase or
Decrease buttons to select a time between 0 to 30 minutes, in 10-second
increments.
PRESSURE Displays the amount of pressure applied to the specimen. Use the Increase
or Decrease buttons to select between 1200 psi to 4400 psi (80 bar – 300
bar), in 100 psi (5 bar) increments.
TEMP-
ERATURE
300F
PRELOAD
PRESSURE
OFF
MOLD
SIZE
1.25IN
Figure 13 Parameter Fields 2
TEMPERATURE Displays the temperature selected. Use the Increase or Decrease buttons to
select a temperature variable between 120 F (50 C) and 360 F (180 C), in
20 F (10 C) increments.
PRELOAD PRESSURE Displays the minimum pressure applied at the beginning of a cycle
before full pressure is applied. Use the Increase or Decrease buttons to
select OFF or a range of psi between 0 psi to 400 psi (0 bar – 30 bar), in
50 psi (5 bar) increments.
MOLD SIZE Displays the mold size selected for the specimen. The automatic mold
sensor will automatically display the mold size. There are eight mold sizes
available.
1 in 25 mm
1.25 in 30 mm
1.50 in 40 mm
2.00 in 50 mm
