18
MA201435_13.1 [Original Instructions] 6/25/2012
Method Screen
HEAT
TIME
1:00min
COOL
TIME
3:00min
PRESSURE
4200psi
PHENOLIC
NEXT
LOADEXIT
PREV
Figure 17 Method Screen parameters
EXIT Returns to the L2 Screen without saving the selected method.
SAVE Loads and saves the parameters of the selected method and exits to the L2
Screen.
NEXT Scrolls to one of the four pre-programmed Buehler Methods (per mold size)
or to the next displayed number of a user-defined method.
PREV Returns to one of the four pre-programmed Buehler Methods or the previous
displayed number of the user-defined method.
