MA201435_13.1 [Original Instructions] 6/25/2012
L2 Screen
UNITS
IMPERIAL
LANGUAGE
ENGLISH
METHOD
LOADED
PHENOLIC
SAVE
METHOD
LOAD
METHOD
L2
Figure 16 L2 Screen parameters
SAVE METHOD Opens a screen to scroll save one of 25 user-defined methods.
LOAD METHOD Opens a screen to scroll through four pre-programmed Buehler Methods
(per mold size) and 25 user-defined methods to operate the press.
Four pre-programmed Buehler Methods:
PHENOLIC
EPOMET
TRANSOPTIC
DIALLYL PH
Note: These methods parameter values can be changed and saved as
user-defined methods (Method 1 – Method 25) to better suit
individual needs.
Level 2 .. Press the L2 button to scroll to the L1 screen for the previous set of command functions.
