Nivotemp NT MD
9.4 Current settings
Switching outputs Basic Settings Diagnostics
SP1 / rP1 o.uni SJ.ou
ds1 / dr1 / ou1 t.uni dt.MM
SP2 / rP2 o.Hi
ds2 / dr2 / ou2 o.Lo
SP3 / rP3 r.ou1
ds3 / dr3 / ou3 r.ou2
SP4 / rP4 r.ou3
ds4 / dr4 / ou4 r.ou4
Di5
Loc
Analogue outputs
tcl*
A1.Hi / A1.Lo / A.ou1 tcC*
A2Hi / A2.Lo / A.ou2
*for wall-mounting only
Date:
Signature:
9.5 Display ranges
Name Menu/Unit Display Range from/
with unit
Range to/
with unit
Temperature
°C ;C ;C -100 °C 999 °C
°F ;F ;F -100 °F 999 °F
Without
none Non none -1000 9999
none Non1 none -100.0 999.9
none Non2 none -10.00 99.99
9.6 Display resolution
Range x = |Max - Min|
°C, °F
(up to 1 decimal)
none (non1)
(1 fixed-point number)
Range
x
Resolution Range
x
Resolution
x < 50 0.1 x < 50 0.1
50 <= x < 100 0.2 50 <= x < 100 0.2
100 <= x < 200 0.5 100 <= x < 200 0.5
200 <= x < 500 1 200 <= x < 500 1
500 <= x < 1000 2 500 <= x < 1000 2
1000 <= x 5 1000 <= x 5
