40417 GT PLATINUM
38
Removing Fuses (GMC/Chevrolet® vehicles only)
This step is vital for successful installation on some vehicles, but not required on others. The following pages include information
about which fuses need to be pulled to allow the GT Platinum to install the tune to the engine computer on specific vehicles. If
the fuses are not pulled, the tune will most likely freeze during the install process. Fuses can be replaced after the tune
installation has been completed.
Replace all fuses after the download is complete!
GMC/Chevrolet ’99-’02 4.8/5.3/6.0/8.1 Liter Engines
Fuse Box Located Inside the Cab:
#1 – SEO IGN (Special Eq. Options/Ignition)
#16 – SEO ACCY (Special Eq. Options/Accessories)
#29 – RD01 (Radio)
#30 – RAP2 (Relay Power)
Fuse Box Located Under Hood:
#60 – TBC (Body Computer)
GMC/Chevrolet ’03-’06 4.8/5.3/6.0/8.1 Liter Engines
Fuse Box Located inside Cab:
#16 – SEO ACCY (Special Eq. Options/Accessories)
#17 – TBC 2B (Body Computer)
#18 – TBC 2C (Body Computer)
#20 – TBC ACCY (Body Computer)
#23 – TBC 2A (Body Computer)
Fuse Box Located Under Hood:
#16 – TBC BATT (Body Computer)
#38 – TBC IGN1 (Body Computer)
#50 – Radio
#58 – INFO
GMC/Chevrolet ’11-’13 6.0 Liter Trucks
#15 – Body Control Module (BCM)
#16 – Accessory Power Outlets
#19 – Rear Seat Entertainment
#20 – Ultrasonic Rear Parking Assist, Power Liftgate
#22 – Driver Information Center (DIC)
Chevrolet ’11-’13 Cruze
#1 – Infotainment System/Hands-free Phone
#3 – Body Control Module
#4 – Infotainment System
#5 – Information Display/Parking Assist
Chevrolet ’12-’13 Sonic
#15 – OnStar
#16 – Ultrasonic Rear Park Assist
#17 – Driver Information Center
#18 – Audio
#21 - CHEVYSTAR
