Bully Dog 40417 - Parts Description; GT Platinum Head Unit

40417 GT PLATINUM
5
PARTS DESCRIPTION
GT Platinum Head Unit
The main component of the Gauge Tuner is the head unit. It has the screen and the buttons that allow you to access all of the
functions and features of the tuner.
GT Platinum Front Side:
The GT Platinum has seven capacitive
touch buttons. Capacitive touch is a but-
ton style that is sensitive to the presence
of your nger. Capacitive buttons do
not need to be pushed, only touched to
activate. The front of the GT Platinum
head unit features a 2.4” LCD screen.
GT Platinum Back Side:
1. T-Slot Mount Socket, which allows you to use the GT Platinum with
dierent mounting options.
2. HDMI port
3. Micro SD card port
4. Mini-USB port
6
1
4
5
2
3
7
1
2
4
3
