LOWLANDER HD MK2 & WIDEBODY MANURE SPREADER – INSTRUCTION & SPARES MANUAL
Page 30
2.5 SHEARBOLT PROTECTION
Only one shearbolt is fitted to the spreader. This is located on the spreader end of the PTO shaft.
The bolt is M10 x 60 grade 6.8 mild steel.
ON NO ACCOUNT MUST A BOLT OF HIGHER GRADE THAN 6.8 TENSILE STRENGTH BE FITTED.
2.6 GREASING POINTS
KEY GREASE POINT
1 ALL BEARINGS IN DRIVE LINE
2 FRONT SHAFT
3 PTO KNUCKLES
4 REAR SHAFT
5 BEARINGS TOP OF AUGERS
2.7 JACKING POINTS
Jack the spreader up on the axle or on the base of the auger turret pressings at the rear to replace
a wheel.
