LOWLANDER HD MK2 & WIDEBODY MANURE SPREADER – INSTRUCTION & SPARES MANUAL
Page 16
1.10 WEIGH CELL SETUP GUIDE – ISOCAN & ISOBUS
1.10.1 BUNNING CUSTOM SETUP
This part of the setup is done at the factory and MUST NOT be changed at any time. If required, it must
only be performed by an authorised Bunning personnel.
1.10.2 VALVE SETUP
It is highly recommended to update the valve calibration if you change tractors.
It is very important to firstly turn the tractor oil down to 50% in forward and reverse.
From the main spread screen, scroll to the MAIN MENU:
Then FACTORY icon and enter the PIN: 1234 (OK)
FACTORY MENU:
CHANNELS: (OK)
Then FEEDBACK (OK) This must be set to the required MACHINE GEARBOX combination.
See the value on the following GEARBOX & MOTOR CONFIGURATION table.
Then VALVE SETUP (OK)
Then VALVE AUTO CAL (OK)
1. Lift slurry door to clear the floor slats
2. Set the engine to normal operating RPM then (OK) when you have set it
3. You should be on the BELT VALVE AUTO: screen
4. Click floor hydraulic spool into work
5. With the MIN DUTY highlighted, using the ⬆⬇ in the top right of the screen, increase the
PWM % until you see the LIVE FEEDBACK: RPM showing a reading of 0.1 - 0.0 RPM and you
can just see the floor is just turning then press (OK).
6. Select MAX DUTY:
7. Run the PWM % to 100% and press (OK)
8. The MAX DUTY RPM should match the approximate rpm of floor shaft on the GEARBOX &
MOTOR CONFIGURATION table for the machine, gearbox and motor combinations. If not, then the
tractor oil flow MUST BE REDUCED until it does.
As the oil flow on the tractor is reduced in stages, press (OK) on the RDS screen to confirm and
recalculate the RPM
Once the required MAX DUTY: RPM has been achieved, then the valve calibration is complete.
GEARBOX TYPE
RT350
BRAND VALVE
57 57 76 114 57 76 114 57 76 114 114 76 114 76 114
ADAN MOTOR
SIZE (CC)
200 200 200 200 200 200
2 x
200
250 250 250
2 x
250
200 200 250 250
FLOOR SHAFT
9 6.5 8.7 13 9 12 9 7.2 9.6 14.4 7.2 9.8 14.7 7.9 11.8
FEEDBACK PPR:
RT500/50 RT800/60 RT1000/70
GEARBOX & MOTOR CONFIGURATIONS
1024
To Next Page
