Burke TRI-FLEX II - Scale System (Optional)

20 TRI-FLEX II BED - OPERATION MANUAL
Scale System System Wiring Diagram (Optional)
TRI-FLEX II SCALE SYSTEM WIRING DIAGRAM
LENGTH OF BED SCALE SYSTEM CABLE 62028
SCALE HEAD 62336
WIDTH OF BED WEIGHT INDICATOR CABLE 62027
LOAD CELL TO SCALE SYSTEM HEAD CABLE 62029
WIDTH OF BED WEIGHT INDICATOR CABLE 62027
LH LOAD CELL 62334 (2) RH LOAD CELL 62333 (2)
LEFT HAND SIDE
RIGHT HAND SIDE
FOOT END HEAD END
