TRI-FLEX II BED - OPERATION MANUAL 5
Mechanical
Total Physical Length, End to End: 94” / 239cm
Total Physical Width: 41” / 104cm
TotalPhysicalWeight:     575lbs/261kg(w/oScaleSystem)
TotalShippingWeight:     650lbs/295kg
Patient Surface Length: 86” / 218 cm
PatientSurfaceWidth:     37”-48”-54”/94cm-121cm-137cm
Patient Surface Transport Width: 37” / 94cm
Deck High: 28” / 71cm
Deck Low: 14” / 36cm
Maximum angle of head gatch elevation: 60 degrees
Maximum angle of upper foot gatch elevation: 24 degrees
Maximum angle of lower foot gatch decline: 26 degrees
Maximum angle of trendelenberg 12 degrees
Electrical
Input Voltage: (refer to label on control box) 120 VAC 60 Hz @ 2.7 AMPS or
        230VAC50Hz/60Hz@1.5AMPS
 Current:      1.5AMPS
Output Voltage: 24 VDC, 70 WATTS max.
 Classication:     ClassBIP-54
Duty Cycle: Intermittent operation/ 10%, 6-min/hr.
 (2)Fusesincontrolbox    5x20mm1.6L250VTime-Lagfuse
        (1.6A/250V)
        WickmannSeries19195orequivalent
Scale System (optional)
Accuracy: Overall 1%
 WeightCapacity:     1000-lbs/454.5kg
Power Requirement: 6x C-size Alkaline
Readings per battery set 8000 (approx)
Options and Accessories
In-Bed Scale System System
Bed Exit Monitor
Underbed Light
Impulse Drive System
Trapeze - Single Arm or 4C/3P
Dual Passage Assist
Specications
Patien Lock-Out
Barri-Float Foam Mattress
Low Air Loss Mattress
Bed Exit Monitor
Wall Bumpers
Manufactured by
Burke, Inc.
1800 Merriam Lane
Kansas City, Kansas
Instructions for use, cleaning and disinfecting for the
above options can be found in the supplemental manuals.
