POSITIONER TYPE 10672 DESCRIPTION
2.5 Technical data
Electrical data
Power supply: 24 VDC
Power consumption: < 10 W
Input for desired value
Input for setpoint for position or process control:
- Unit signal 4 ... 20 mA
- Unit signal 0 ... 20 mA
- Unit signal 0 ... 10 V
Input for process signal (in case of process control):
- Unit signal 4 ... 20 mA
Binary input: Can be configured as a normally open or normally
closed contact.
Terminations: 1.5 mm
2
bolted terminals
Two PG 9 screwed glands
Pneumatic data
Control medium: filtered compressed dry air, oiled or non-oiled
Pressure range: 0 ... 6 bar
Air rates
Inlet valve: 23 Nl / min
(1)
Exhaust valve: 25 Nl / min
(1)
Air consumption by unit
in stable state: 0 Nl / min
Unions: G 1/8" internal thread
(1)
When pressure reduction from 6 to 5 bar
Mechanical data
Regulation range of internal path-measuring system:
lift turn: 10...80 mm
rotary movement: 0...180°
Regulation range of external path-measuring system:
lift turn: 0...50 mm
Process controller data
Proportional correction value KP: 0...99,99
Reset time TN: 0.5...999.9
Rate time TV: 0.0...999.9
Operating point: 0...100%
Installation and operating data
External dimensions of positioner : 125 mm x 80 mm x 80 mm (W x H x D)
Material of body: Aluminium, lacquered
Material of the fluid plate: Aluminium, anodised
Weight of positioner: Approx. 1 kg
Degree of protection: IP 65
Operating temperature: 0 ... 60 °C
