Why is my Bürkert Controller not working despite correct settings?
If the Bürkert Controller device isn't operating as a controller despite correct settings, it might be because the 'P.CONTROL' menu option is in the main menu. This makes the device function as a process controller, expecting a process actual value at the input. To resolve this, remove the 'P.CONTROL' menu option from the main menu.
What to do if the digital output of Bürkert Controller does not switch?
If the digital output of your Bürkert Controller isn't switching, the cause might be excessive current (greater than 100 mA) or a short-circuit. Check the digital output connection to resolve this.
How to fix 'Other device with the same address' error on Bürkert Controller?
If your Bürkert Controller shows that another device has the same address on the network, causing BUS offline issues, change the address of the device and restart it. You may also perform a fault analysis in the network using a bus monitor.
What to do if Bürkert Controller shows no supply pressure connected?
If your Bürkert Controller displays a message indicating that no supply pressure is connected and there is no change to the process variable, connect the supply pressure. Also, check the process and, if needed, switch on the pump or open the shut-off valve. Finally, check the process sensor.
Why can't Bürkert Controller find a configured partner?
If the Bürkert Controller indicates that a configured partner (Producer) cannot be found, verify that the configured partner is switched on and connected to the büS network. Also, check the bueS mapping using the Communicator.
What to do if compressed air failed during Autotune (X.TUNE) on Bürkert Controller?
If compressed air failed during Autotune (X.TUNE) on your Bürkert Controller, check the compressed air supply.
What to do if POS-MIN and POS-MAX are too close together on Bürkert Controller?
If the end positions for POS-MIN and POS-MAX are too close together on your Bürkert Controller, check the compressed air supply.
How to unblock X.TUNE function on Bürkert Controller?
If the X.TUNE function is blocked on your Bürkert Controller, input the access code.
What to do if I entered the wrong access code on Bürkert Controller?
If you've entered an incorrect access code on your Bürkert Controller, enter the correct access code.
What happens if maximum input value has been reached on Bürkert Controller?
If you've reached the maximum input value on your Bürkert Controller, do not increase the value further.
General| Brand | Burkert |
|---|---|
| Model | 8693 |
| Category | Valve Positioners |
| Language | English |
Explains warning, danger, caution symbols used in the manual.
Outlines limitations for system/device export.
Lists prohibited uses and handling of the positioner.
Details items included in the delivery.
Explains warranty conditions and limitations.
Information about device lock and master code.
Points to online resources for documentation.
Describes the two available versions of the positioner.
Details characteristics of different valve types used with the positioner.
Illustrates the physical components of the positioner.
Lists key functional and physical characteristics of the positioner.
Shows the operational flow of the positioner.
Provides a block diagram of the Type 8692 positioner.
Lists features and actions of the position controller software.
Illustrates the process control system for Type 8693.
Details functions and properties of the process controller software.
Specifies actuator behavior during power loss.
Lists default configuration parameters for the positioner.
Details various specifications of the positioner.
Identifies the physical control and display components on the unit.
Explains the function of each key based on operating status.
Describes the data shown on the positioner's display.
Differentiates between AUTOMATIC and MANUAL operating states.
Details display options in AUTOMATIC mode for Type 8692.
Details display options in AUTOMATIC mode for Type 8693.
Explains manual valve control and key functions.
Describes how to navigate between process and configuration levels.
Crucial safety precautions for valve installation.
Guidance on connecting the process valve.
Identifies connector pinouts for Type 8692.
Details input signal connections for Type 8692.
Details output signal connections for Type 8692.
Specifies power supply connections for Type 8692.
Details process actual value connections for Type 8693.
Illustrates the terminal board layout.
Lists terminal assignments for Type 8692 cable gland.
Lists terminal assignments for Type 8693 cable gland.
Safety precautions before initial start-up.
Brief mention of prior installation steps.
Steps for initial configuration and parameterization.
Outline of the steps for starting up the position controller.
Lists the default parameters for the position controller.
Guides on essential initial configuration steps.
Explains the structure and options of the main menu.
How to toggle between AUTOMATIC and MANUAL modes.
Navigating between process and configuration levels.
Details key functions and display info in AUTOMATIC mode.
Details key functions and display info in MANUAL mode.
Key functions when in configuration mode.
Guides on adding/removing functions and setting values.
Details various auxiliary functions like CHARACT, CUTOFF, X.CONTROL.
Outline of steps for setting up the process controller.
Lists the default parameters for the process controller.
Steps for configuring process control functions.
Guides on configuring basic positioner settings.
Guides on configuring process controller settings.
How to toggle between AUTOMATIC and MANUAL modes.
Navigating between process and configuration levels.
Details key functions and display info in AUTOMATIC mode.
How to manually adjust the process set-point value.
Details key functions and display info in MANUAL mode.
Lists auxiliary functions specific to the process controller.
Adds custom functions to the main menu.
Removes custom functions from the main menu.
Defines valve sealing behavior outside control range.
Protects access to settings with a code.
Configures detection of input signal faults.
Configures analogue and binary outputs for feedback.
Manually calibrates display values and inputs.
General overview of PROFIBUS-DP functionality.
Technical specifications for PROFIBUS-DP interface.
Defines behavior when the PROFIBUS connection fails.
Overview of PROFIBUS interfaces.
Details PROFIBUS electrical connection diagrams.
Configuration settings accessible via the PROFIBUS menu.
Highlights differences from standard operation with PROFIBUS.
Process for configuring PROFIBUS DP master settings.
Indicates the status of the PROFIBUS connection.
Examples for configuring with Siemens STEP7 software.
General overview of DeviceNet functionality.
Defines key terms related to DeviceNet.
Technical specifications for DeviceNet interface.
Defines behavior when the DeviceNet connection fails.
Overview of DeviceNet interfaces.
Details DeviceNet electrical connection diagrams.
Configuration settings accessible via the DeviceNet menu.
Highlights differences from standard operation with DeviceNet.
Defines input/output data structures for DeviceNet.
Indicates the status of the DeviceNet connection.
Guides on EDS file installation and address assignment.
Example for setting up the process image (mapping).
Information regarding maintenance requirements for the position controller.
Lists error messages and their causes/remedies.
Information regarding maintenance requirements for the process controller.
Lists error messages and their causes/remedies for Type 8693.
Guidelines for safe packaging and transport of the device.
Recommendations for proper storage conditions.
Instructions for environmentally friendly disposal of the device.
Explains the proportional part of a PID controller.
Explains the integral part of a PID controller.
Explains the derivative part of a PID controller.
Describes how P, I, and D parts combine in a PID controller.
Details implementation of PID controller components.
Method for tuning PID controllers via oscillation.
Method for tuning PID controllers via variable jump.
Visual representation of the positioner's operational structure.
Table to record settings for programmable valve characteristics.
Table to record settings for programmable valve characteristics.
Table to record process controller parameters.
Provides the master code for device access.
