Type 8692, 8693
english
Start-up, operation
process controller Type 8693
2.4 Setting up the position controller
Specification of the basic settings is described in the chapter entitled "Start-up and operation of the position controller
Type 8692" - "Specifying the basic settings".
When starting up the positioner for the first time, implement the following basic settings:
Specify the selected unit signal input for the set-point value default (
→ INPUT)
(4 – 20 mA, 0 – 20 mA, 0 – 10 V or 0 – 5 V).
Start automatic adjustment of the position controller to the particular operating conditions ( → X.TUNE).
The exact description of the functions INPUT and X.TUNE can be found in the chapter entitled "Start-up and opera-
tion of the position controller Type 8692“ -"Description of the functions of the main menu”.
The basic settings for the positioner are implemented at the factory. During start-up, however, it is essential to input
the unit signal (INPUT) and run X.TUNE . Using the X.TUNE function, the positioner automatically determines the
optimum settings for the current operating conditions.
2.5 Setting up the process controller
2.5.1 Starting the P.CONTROL auxiliary function
How to start the auxiliary functions is described in the chapter entitled "Start-up and operation of the position control-
ler Type 8692" - "Configuring the auxiliary functions".
Press the left selection key (MENU) to switch to the configuration level in the main menu (MAIN).
→
Press the arrow keys to select the → ADD.FUNCTION menu option and confirm by pressing the right selection key (ENTER).
Press the arrow keys to select the
→ ADD.FUNCTION menu option and confirm by pressing the right selection key (ENTER).
Press the left selection key (EXIT) to return to the main menu. →
The main menu now contains the P.CONTROL and P.Q‘LIN auxiliary functions.
