32
Type 8692, 8693
english
Control and display elements,
operating modes
1 CONTROL AND DISPLAY ELEMENTS
The following chapter describes the control and display elements of the positioner.
Further information on the control of the positioner can be found in the chapters entitled “Installation”, “Start-up and operation
of the position controller Type 8692” and “Start-up and operation of the process controller Type 8693”.
1.1 Control and display elements of the positioner
MENU INPUT CMD MANU
POS
%
XXX
Up arrow key
Description of con-
figuration of the keys
left selection key right selection key
Display
Down arrow key
Fig. 1: Description of the control module
The positioner features a 4-key control panel and a 128x64 dot matrix graphics display as a display element.
