position controller Type 8692
4.3 Auxiliary functions
Overview of auxiliary functions for the position controller Type 8692
ENTER
CHARACT
EXIT
ADD.FUNCTION
Selection of the transfer characteristic between input
signal and stroke (correction characteristic)
CUTOFF
Sealing function for position controller
DIR.CMD
Effective sense of direction between input signal and
nominal position
DIR.ACT
Assignment of the aeration state of the actuator cham-
ber to the actual position
SPLTRNG
Signal split range; input signal as % for which the
valve runs through the entire stroke range.
X.LIMIT
Limit of the mechanical stroke range
X.TIME
Limiting the control speed
X.CONTROL
Parameters for the position controller
SECURITY
Code protection for settings
SAFEPOS
Inputting the safety position
SIG.ERROR
Configuration of signal level fault detection
BINARY. IN
Activating of the binary input
OUTPUT
Configuration of the outputs (only with auxiliary board
for analogue feedback signal or binary outputs)
CAL.USER
Calibration
SET.FACTORY
Reset to factory settings
SER. I / O
Configuration of serial interface
EXTRAS
Set colours on display
SERVICE
For internal use only
Fig. 10: Overview - auxiliary functions
